ROCKSOLAR 3500W 48V Off-Grid Solar System
- Complete System: Includes batteries, panels, inverter, and controller.
- High-Capacity Battery: Two 48V 50Ah LiFePO4 batteries with BMS.
- Efficient Solar Panels: Eight 200W Monocrystalline, 22% efficiency.
- Powerful Inverter: 3.5KW off-grid solar inverter for sensitive devices.
- Durable & Safe: Waterproof panels, BMS-protected battery.
- Versatile: Powers multiple devices, constant supply.
- Extended Warranty: 10 years for batteries and panels.
- Easy Installation: Pre-drilled holes, lightweight design.
- Future-Proof: Upgradeable for increased power needs.
- Wide Temperature Range: Battery -20°C to 60°C; inverter/controller also tolerant.
ROCKSOLAR 3500W 48V Off-Grid Solar System is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Free Shipping
Free Shipping
Orders Over $100? Shipping's On Us!
Hassle Free Warranty
Hassle Free Warranty
Effortless Warranty for Your Ease.
Lifetime Customer Support
Lifetime Customer Support
Endless Support, Because You Matter.
Description
Description
The ROCKSOLAR 3500W 48V Off-Grid Solar System offers the most comprehensive power solution yet for Canadian cottage/rv owners. It boasts reliability and high efficiency, providing off-grid power at your convenience. The system consists of 2x 48V 50AH LiFePO4 Batteries, 8x 200W Rigid Solar Panels, and a potent 6KW Off-Grid Solar Inverter. It is designed to power a wide array of appliances including a mini fridge, freezer, LCD TV, wifi router, coffee machine, microwave, lighting, stereo, laptop, and phone chargers, ensuring a 24/7 off-grid power supply for all your cottage needs. The ROCKSOLAR Cottage Life Series V comes with a future-focused design that allows easy upgrades for increased power needs, providing free upgrade services and exchangeable key components. ROCKSOLAR guarantees the value retention of all components, making sure your investment is worthwhile. The batteries and solar panels come with a reassuring 10-year warranty, while the other components carry a 2-years warranty. Embrace a worry-free cottage life with the ROCKSOLAR Cottage Life Series V Off-Grid Solar System.
Product Features
ROCKSOLAR 48V 50Ah Deep Cycle LiFePO4 Battery with BMS System (2 pcs):
- 48V 50AH capacity
- 3500+ cycle life with 100% discharge rate for ultra-long service life
- Steady power: Flat voltage curve for consistent power output, no significant drop like traditional SLA batteries
- Utilizes advanced LiFePO4 Battery Technology for dependable deep cycling
- Smart Battery Management System for safety and longevity
- Lightweight: Only 53 lbs. for easy portability and installation
- Suitable for harsh environments: Built-in BMS provides protection against temperature fluctuations, short circuits, over-discharge, over-current, and overcharge, and ensures battery cell balancing.
- Operating temperature range for charging: 0°C to 45°C, discharging: -20°C to 60°C
- BMS auto-shuts off the battery outside the working temperature.
- Warranty: 10-year warranty and 10+ year service life
ROCKSOLAR 200W 12V Rigid Monocrystalline Solar Panel (8 Pcs):
- 200W 12V output (each)
- Rigid Monocrystalline Solar Panel
- Waterproof and Corrosion-Resistant Aluminum Alloy Frame
- High-Efficiency Solar Cell with 22% Conversion Efficiency
- Pre-drilled holes for easy mounting and securing to any surface
Growatt 3.5KW Off-Grid Solar Inverter:
- Integrated MPPT: Features an advanced MPPT charge controller for maximum solar energy efficiency.
- Battery Versatility: Operates with or without a battery, providing flexible energy solutions.
- High PV Input: Accepts up to 280VDC of PV input, allowing for a wide range of solar panel options.
- Generator Ready: Equipped with a generator connection for additional power options.
- Expandable Power: Supports parallel operation for capacity expansion up to 21kW.
- Smart Monitoring: Optional WIFI/GPRS remote monitoring for convenient system management.
- Priority Configuration: Configurable grid or solar input priority to optimize energy use.
- Quick Transfer: Transfer time is 10ms typical, ensuring minimal interruption during power source changeover.
- Durable Construction: Designed to operate within a wide temperature range for various environments.
- Comprehensive Warranty: Comes with a 2-year warranty for peace of mind and reliability.
SPECIFICATIONS
SPECIFICATIONS
48V 50Ah Deep Cycle Lithium Battery (LIFEPO4) Details
Nominal capacity | 50Ah |
Max. capacity | 49Ah |
Nominal energy | 2560Wh |
Combination structure of battery | 16S |
Nominal voltage | 51.2V |
End of discharge voltage | 43.2V |
Standard charge voltage | 58.4±0.2V |
Float charge voltage | 55.2V |
Standard charge current | 10A |
Recommended charge current | ≤25A |
Allowed Max. charge current | 50A |
Standard discharge current | 10A |
Recommended discharge current | ≤50A |
Allowed Max. discharge current | 50A |
Peak discharge current | 100A, 10Sec |
Internal Resistance | ≤80mΩ |
Weight | Approx. 24kg |
Ex-factory capacity | Approx. 50% SOC |
Operation temperature | Discharge: -20°C~60°C; Charge: 0°C~45°C |
Storage environment | ≤1Month: -20~+60°C, 5~75%RH; ≤6Month: -10~+45°C, 5~75%RH; Recommend environment: 15~+35°C, 5~75%RH |
200W 12V Rigid Solar Panel Details
Panel Type | Monocrystalline |
Power Output | 200W |
System Voltage | 12V |
Cell Efficiency | 20-22% |
Frame Material | Aluminum |
Dimensions | 1480mm x 670mm |
Weight | approx. 25-30 lbs |
Operating Temperature | -40°C to +85°C |
Waterproof Rating | IP65 |
Front Glass | High light transmittance, low-iron tempered glass |
Bypass Diodes | Integrated |
Connectors | MC4 |
Cable Length | Varies depending on the brand (approx. 3-6 ft) |
Mounting Hole Locations | Pre-drilled |
Service Life | 25 years or more |
Warranty | 10 years |
Growatt 3.5KW Off-Grid Solar Inverter Details
Battery Voltage | 48VDC |
Battery Type | Lithium/Lead-acid |
Inverter Output | Rated Power: 3500VA 3500W |
Parallel Capability | Yes, 6 units maximum |
AC Voltage Regulation (Battery Mode) | 100Vac/110Vac/120Vac @ 50/60Hz |
Surge Power | 6000VA |
Efficiency (Peak) | 90% |
Waveform | Pure Sine Wave |
Transfer Time | 10ms typical, 20ms max |
Solar Charger | Maximum PV Array Power: 4000W |
MPPT Range @ Operating Voltage | 120VDC – 225VDC |
Maximum PV Array Open Circuit Voltage | 280VDC |
Maximum Solar Charge Current | 80A |
AC Charger | Charge Current: 40A |
AC Input Voltage | 120VAC |
Selectable Voltage Range | 95-140VAC (For Personal Computers); 65-140VAC (For Home Appliances) |
Frequency Range | 50Hz/60Hz (Auto sensing) |
Physical Protection Degree | IP20/NEMA Type1 |
Dimension (W/H/D) | 330/485/135mm |
Net Weight | 12kg |
Operating Environment Humidity | 5% to 95% Relative Humidity (Non-condensing) |
Operating Temperature | 0°C - 50°C (32°F - 122°F) |
Storage Temperature | -15°C - 60°C (-5°F - 140°F) |
Warranty | 2 Years |
